| JH-150 Water Well Drilling Rig Specification | |||||||
| Drilling depth | 150m | ||||||
| Drilling Diameter | 130-219mm | ||||||
| Drilling rod diameter | 76mm | ||||||
| One-time propulsion length | 3300mm | ||||||
| Dimensions(L×W×H) | 3400×1450×2000 (mm) | ||||||
| Weight | 4300kg/set | ||||||
| Walking speed | 2km/h | ||||||
| Standalone climbing ability | 25Max. | ||||||
| Minimum distance between ground | 250mm | ||||||
| Working Pressure | 1.45-2.5Mpa | ||||||
| Host Power | 37-55KW | ||||||
| Air consumption | 15-27 cbm/min | ||||||
| Rotary torque | 4000-5000 N.M | ||||||
Mud Pump | |||||||
| Model | BW-250 | ||||||
| Type | Horizontal three-cylinder reciprocal effect piston pump | ||||||
| Cylinder diameter (mm) | 80 | 65 | |||||
| Flushing Times(minˉ¹) | 200 | 116 | 72 | 42 | 200 | 116 | 72 |
| Displacement (L/min) | 250 | 145 | 90 | 52 | 166 | 96 | 60 |
| Working pressure (Mpa) | 2.5 | 4.5 | 6.0 | 6.0 | 4.0 | 6.0 | 7.0 |
| Drive shaft speed | 500 r/min | ||||||
| Total Power | 15KW | ||||||
| Diameter of inlet pipe | 76mm | ||||||
| Diameter of outlet pipe | 51mm | ||||||
| Volume | 1000×995×650mm | ||||||
